RJH60D5BDPQ-E0#T2
IGBT TRENCH 600V 75A TO247
part Number：
RJH60D5BDPQ-E0#T2
manufacturer：
Intersil (Renesas Electronics Corporation)
category：
Discrete Semiconductor Products >
Transistors >
IGBTs >
Single IGBTs >
describe：
IGBT TRENCH 600V 75A TO247
RoHS：
YES
RJH60D5BDPQ-E0#T2 specifications
Mounting Type：
Through Hole
Power - Max：
200 W
Operating Temperature：
150°C (TJ)
IGBT Type：
Trench
Reverse Recovery Time (trr)：
25 ns
Voltage - Collector Emitter Breakdown (Max)：
600 V
Input Type：
Standard
Package / Case：
TO-247-3
Current - Collector (Ic) (Max)：
75 A
Supplier Device Package：
TO-247
Gate Charge：
78 nC
Vce(on) (Max) @ Vge, Ic：
2.2V @ 15V, 37A
Test Condition：
300V, 37A, 5Ohm, 15V
Td (on/off) @ 25°C：
50ns/130ns
Switching Energy：
400µJ (on), 810µJ (off)
