CM600DXL-24S
IGBT MOD 1200V 600A 4545W
part Number：
CM600DXL-24S
Alternative Model：
MGJ2D121505SC , MGJ2D241505SC , MGJ2D051505SC , MGJ3T12150505MC-R7 , MGJ6T24150505MC-R7 , MGJ2D151505SC , MGJ6T12150505MC-R7 , MGJ3T24150505MC-R7 , MGJ3T05150505MC-R7 , MGJ6T24150505MC-R13
manufacturer：
Powerex, Inc.
category：
Discrete Semiconductor Products >
Transistors >
IGBTs >
IGBT Modules >
describe：
IGBT MOD 1200V 600A 4545W
RoHS：
YES
CM600DXL-24S specifications
Package / Case：
Module
Operating Temperature：
-40°C ~ 150°C (TJ)
Supplier Device Package：
Module
Voltage - Collector Emitter Breakdown (Max)：
1200 V
Input：
Standard
NTC Thermistor：
Yes
Current - Collector (Ic) (Max)：
600 A
Current - Collector Cutoff (Max)：
1 mA
Configuration：
Half Bridge
Vce(on) (Max) @ Vge, Ic：
2.3V @ 15V, 600A
Input Capacitance (Cies) @ Vce：
60 nF @ 10 V
Power - Max：
4545 W
