PDTC144WMB,315
TRANS PREBIAS NPN 50V 0.1A 3DFN
part Number：
PDTC144WMB,315
manufacturer：
Nexperia
category：
Discrete Semiconductor Products >
Transistors >
Bipolar (BJT) >
Single, Pre-Biased Bipolar Transistors >
describe：
TRANS PREBIAS NPN 50V 0.1A 3DFN
RoHS：
YES
PDTC144WMB,315 specifications
Mounting Type：
Surface Mount
Grade：
Automotive
Power - Max：
250 mW
Qualification：
AEC-Q100
Voltage - Collector Emitter Breakdown (Max)：
50 V
Current - Collector (Ic) (Max)：
100 mA
Transistor Type：
NPN - Pre-Biased
Resistor - Emitter Base (R2)：
22 kOhms
Resistor - Base (R1)：
47 kOhms
Vce Saturation (Max) @ Ib, Ic：
150mV @ 500µA, 10mA
Current - Collector Cutoff (Max)：
1µA
Frequency - Transition：
230 MHz
DC Current Gain (hFE) (Min) @ Ic, Vce：
60 @ 5mA, 5V
Supplier Device Package：
DFN1006B-3
Package / Case：
3-XFDFN
